Wireless Plate Amp Up2stream Plate Amp

Name: Wireless Plate Amp Up2stream Plate Amp
Brand: arylic
SKU: U2S-PAMP
Price: 169.0 USD
Availability: InStock

$189.00 $169.00

🌍Deliver to worldwide from Asia
🚚Local delivery from US/EU/RU
📦Available in stock US✔ EU✔ RU✔ Asia✔
Check our shipping policy to know more details

Model

U2S-PAMP

Button Board

SPDIF Input Board

SPDIF Output Board

IR Extension Board

Quantity

1 Year Warranty
14 Days Return
Free Shipping
EU/US/RU Warehouse
24/7 Online Chat Support

DESCRIPTION
SPEC
Q & A
REVIEWS

Wireless Plate Amp for Easy DIY Solution

DIY your Versatile Wireless Speaker

With Up2stream Plate Amp integrated to your speakers, you can stream and control audio remotely by Wifi, Bluetooth, Airplay 1 and Spotify connect. Enjoy sound without distance limitation and the premium quality by wifi streaming.

Easy Installation

The compact and thoughtful design allows you easy to DIY without needing to analysis the ports dimensions and how to wire the speakers or how to use the pins. You can install to your designed speaker chassis directly.
Powerful Stereo

Up2stream Plate Amp is 40W*2 amplifier board which could meet your plenty of use like bedroom, kitchen, workshop or computer desk to stream powerful sounds wirelessly.

Personalize your Sounds.

Up2stream Plate Amp support streaming from PC directly and you can customize the precise EQ settings with our ACPWorkbench tuning tool.

Premium Sound

The amplifier chips on Up2stream Plate Amp is ma12070p that has premium sound performance and high efficient with audio processing.

Control All Audio by One System

All Arylic products are compatible to group and stream audio to each others. So you can DIY your whole house audio for everyroom, play and sync sounds to each room by Arylic devices.

Stream All Music you Like

Stream your favorite online music such as Spotify, Amazon Music(US Only), Tidal, Deezer, Qobuz, Internet Radio, iheartRadio, Napster etc. Any time anywhere in your house with our 4stream App.

What's More

Package

Specification

USER INTERFACE & CONTROLS LED indicators White-WiFi & network mode: Flashing fast-device is booting Flashing slow- waiting for WiFi connection Solid- WiFi is connected Blue-Bluetooth mode Flashing slow- waiting for Bluetooth connection Solid- Bluetooth is connected Green-Line in mode Flashing slow- waiting for line in connection Solid- Line in is connected Yellow-connect to PC Power Button Device on: Short press once: Switch input mode Long press once: Switch off Short press twice: Disconnect current WiFi connection and enter paring mode (WiFi mode) Short press three times: Restore the factory settings Device off: Short press: Switch on Volume Knob Adjust volume PC iTunes/Musicbee/Foobar 2000 4stream App Free iOS and Android App	AUDIO Music Format FLAC/MP3/AAC/AAC+/ALAC/APE/WAV Audio Decode Up to 24bit/192kHz Audio Output 44.1khz/16bits, CD quality Frequency Response 20Hz-20kHz THD+N <0.9% @ 1KHz, 1W Crosstalk >55dB @1KHz SNR ≥85dB @ max Speaker Impedance 4-8Ω Speaker Power 40W x2 @4Ω 20W x2 @8Ω Online Music Service Check here Local Storage Mobile device memory, NAS	GENERAL Weight 0.3kg Dimensions 135.3 x 85.3 x 77.3 mm Working temperature 0~40℃ Screw Dimensions KM 3.5mm1.5mm Package Included* Main board x1 Antenna x2 User's manual x1 Power cord x1 USB Cablex1 EVA Sticker x4
	CONNECTIVITY Wifi IEEE 802.11 b/g/n 2.4G Bluetooth 5.0 SBC/AAC, 10M Wired Connection Ethernet RJ45 Streaming Protocols AirPlay, DLNA, UPnP, Spotify connect, Qplay	INTERFACES Power input AC100-240V 50/60Hz 1A Audio input 3.5mm mini jack（1Vrms） Spdif in(pin) Type A USB Input x1 for PC streaming Audio output Subwoofer Output(20-300Hz Max 2V RMS) Line out(Left channel speaker output) Antennas WiFi/Bluetooth Signal Compatible Expansion Board (Need to wire to correspond port yourself) ADC-KEY Board SPDIF Input Board SPDIF Output Board IR Extension Board (need to use with ADC-key board)

Specification

USER INTERFACE & CONTROLS LED indicators White-WiFi & network mode: Flashing fast-device is booting Flashing slow- waiting for WiFi connection Solid- WiFi is connected Blue-Bluetooth mode Flashing slow- waiting for Bluetooth connection Solid- Bluetooth is connected Green-Line in mode Flashing slow- waiting for line in connection Solid- Line in is connected Yellow-connect to PC	Power Button Device on: Short press once: Switch input mode Long press once: Switch off Short press twice: Disconnect current WiFi connection and enter paring mode (WiFi mode) Short press three times: Restore the factory settings Device off: Short press: Switch on Volume Knob Adjust volume PC iTunes/Musicbee/Foobar 2000 4stream App Free iOS and Android App
AUDIO Music Format FLAC/MP3/AAC/AAC+/ALAC/APE/WAV Audio Decode Up to 24bit/192kHz Audio Output 44.1khz/16bits, CD quality Frequency Response 20Hz-20kHz THD+N <0.9% @ 1KHz, 1W Crosstalk >55dB @1KHz SNR ≥85dB @ max Speaker Impedance 4-8Ω Speaker Power 40W x2 @4Ω 20W x2 @8Ω Online Music Service Check here Local Storage Mobile device memory, NAS	GENERAL Weight 0.3kg Dimensions 135.3 x 85.3 x 77.3 mm Working temperature 0~40℃ Screw Dimensions KM 3.5mm1.5mm Package Included* Main board x1 Antenna x2 User's manual x1 Power cord x1 USB Cablex1 EVA Sticker x4
CONNECTIVITY Wifi IEEE 802.11 b/g/n 2.4G Bluetooth 5.0 SBC/AAC, 10M Wired Connection Ethernet RJ45 Streaming Protocols AirPlay, DLNA, UPnP, Spotify connect, Qplay	INTERFACES Power input AC100-240V 50/60Hz 1A Audio input 3.5mm mini jack（1Vrms） Spdif in(pin) Type A USB Input x1 for PC streaming Audio output Subwoofer Output(20-300Hz Max 2V RMS) Line out(Left channel speaker output) Antennas WiFi/Bluetooth Signal Compatible Expansion Board (Need to wire to correspond port yourself) ADC-KEY Board SPDIF Input Board SPDIF Output Board IR Extension Board (need to use with ADC-key board)

Download

Want to get a 30 to 50% discount on this item?
Why Not! Just write a review and let us know after your purchase.

To Know More here.

QUESTIONS & ANSWERS

Ask a Question

Can you set the Up2stream Plate Amp in PBTL mode and run two plate amps, one for each stereo speaker?

This is not supported, but you can achieve the same goal with our ACPWorkbench tool.
Adjust the ouput mode to mono in the tool
I'm looking for something similar to the "Wireless Plate Amp Up2stream Plate Amp" withe the antennas, power connection, and speakers behind the wall/plate so only the knob would be exposed when screwed into the wall (the connections to the power and in-ceiling speakers would be behind the wall/plate). Do you have any products like this?

We don't have the product currently, but I can share you what other customer did.

They usually buy our diy amplifier board and wire to their celing speaker or wall speaker then hide inside.
For volume button, you can add yourself here.

And we have other on-wall amplifier and celing speaker here.
We will release a wall mount cube speaker soon recently.

You can check at that time also.
Hello, I would like to build wirelles speaker, without any cables. Could you advice please which your module would be suitable to support Left speaker and Rigt speaker without any cables? I'm thinking about configuration where one module is inside Left speaker and second module is inside Right speaker. Can I configure it is such way to obtain full synchronization in time domain? I'm wondering whether Left module can play without any phase shift or time dalay in refference to Right module? Power supply and amplifier will be buid by me. I'm going to use smartphone and TIDAL as audio source. Thank you for your help. Regards, Robert

Would you like to build a satellite or a stereo speaker in a case.
If you want to do satellite, I reommend you can choose Up2stream Amp Mono to each channel. Then set one as left, one as right in our 4stream App.
And set left or right as master to sync the audio in our 4stream App. Is hard to hear a delay when playing music, TV may have some. A liitle bit.

And if you are going to make a stereo speaker in a case, you can pick Up2stream Amp V4, which you can seting left and right channel to your speaker directly.
So there won't have any delay.

If you need more help, you can contact info@arylic.com

●It is extendable by expansion boards.

*5G WiFi compatiable means users could control our system when your smartphone connected to your router's 5G channel.

* About Spidif Pins, Up2stream Mini/Pro is default as Spdif out. Up2stream Amp/Mono is default as Spdif in. You can switch to Spdif In/Out by ACPWorkbench Tool. The 2 spdif pins are the same funtion, can't change seperately.

*Up2stream Amp SUB and S50 Pro+ Preamp is our coming up new products.
